API PAYIN

Request

The Pay-In API enables merchants to initiate payment collection transactions from customers.
Supported payment methods include:

QRPAY (Quick Response Payment)
Bank transfers
Digital wallets
Credit/debit cards
Other digital payment channels

Request Path:

sandbox: https://sandbox-gateway.smilepayz.com/v2.0/transaction/pay-in
production: https://gateway.smilepayz.com/v2.0/transaction/pay-in

Header Parameters

Field	Required	Type	Description
Content-Type	M	String	HTTP content type specification Fixed value: application/json Required for proper request parsing
X-TIMESTAMP	M	String	ISO 8601 datetime format with timezone offset Format: yyyy-MM-ddTHH:mm:ss±HH:mm Example: 2020-12-17T10:55:00+07:00 Note: Must be current server time within ±5 minutes
X-SIGNATURE	M	String	Digital signature for request authentication. See Signature Generation
X-PARTNER-ID	M	String	Unique merchant identifier assigned by the platform Format: Alphanumeric string Used for merchant authentication and transaction routing Please enter merchantID

Body Parameters

Field	Required	Type	Description
orderNo	M	String(32)	Unique transaction identifier for merchant tracking Format: Alphanumeric characters only Length: 6-32 characters Must be unique within merchant scope
purpose	M	String(64)	Human-readable transaction description Format: UTF-8 encoded string Length: 1-64 characters Used for transaction history and reporting
merchant	M	Object	Merchant identification and business information container Contains primary and sub-merchant details Required for transaction routing and settlement
merchantId	M	String	Primary merchant identifier assigned by the platform Format: Alphanumeric string Used for transaction routing and settlement processing
merchantName	O	String	Registered business name of the merchant Format: UTF-8 encoded string Displayed in payment interface and transaction records
subMerchantId	O	String	Sub-merchant identifier for multi-level merchant structures Format: Alphanumeric string Required for sub-merchant transaction processing
subMerchantName	O	String	Sub-merchant business name for display purposes Format: UTF-8 encoded string Shown in payment interface and transaction records
money	M	Object	Transaction amount and currency specification container Defines payment value and monetary unit Required for payment processing and settlement
currency	M	String	ISO 4217 currency code specification Fixed value: THB (Thai Baht) Determines payment processing rules and settlement currency
amount	M	Number	Transaction amount in smallest currency unit Format: Integer value Example: 200 represents THB 200.00 Range: 100-999999999
payer	M	Object	Customer payment information container Used for payment verification and customer communication
name	M	String	Customer full name for payment verification Format: UTF-8 encoded string Used for payment processing and transaction records
accountNo	M	String	Customer bank account number for payment processing Format: numeric string Used for bank transfer payment verification
bankName	M	String	Customer bank name for payment processing Format: Predefined bank codes Examples: KBANK, BBL, SCB See Payment Method List
paymentMethod	M	String	Preferred payment method specification Fixed Value: `QRPAY` or `KBANK` See Payment Method List
expiryPeriod	O	Number	Payment session timeout duration in seconds Format: Integer value Default: 3600 seconds (1 hour)
redirectUrl	O	String(256)	Post-payment redirect destination URL Format: Valid HTTP/HTTPS URL Maximum length: 256 characters Customer is redirected here after payment completion
callbackUrl	O	String(256)	Webhook notification endpoint URL Format: Valid HTTP/HTTPS URL Maximum length: 256 characters Receives real-time transaction status updates

Important Notes

1. Payment Method Selection: If paymentMethod is not specified, Smilepayz will return a checkout page for customers to select their preferred payment method

2. Payer Information Requirement: When paymentMethod is specified, you must provide the payer name, account number, and bank name for payment verification

3. Bank Name Reference: For supported bank names, please see Payment Method List

Example Body – Transaction Request:

Content-type: application/json
X-TIMESTAMP: 2020-12-17T10:55:00+07:00
X-SIGNATURE: 7MHd9v5/m9JeqmDZVwWBZUZ5J5...7120QnFEny7Qm7uQR1G0TWCh10fsU6nVxiRoeoQ==
X-PARTNER-ID: 20001

{
    "payer": {
        "name": "test",
        "accountNo": "123456789009",
      "bankName": "KBANK"
    },
    "merchant": {
        "merchantId": "20001"
    },
    "money": {
        "amount": 10000,
        "currency": "THB"
    },
  "orderNo": "20001e9d98b010db244c99d457c",
    "paymentMethod": "QRPAY",
    "purpose": "Purpose For Transaction from Java SDK",
    "redirectUrl": "https://docs.smilepayz.com/en/"
}

Response

HTTP Response

Field	Required	Type	Description
Content-Type	M	String	HTTP response content type specification Fixed value: application/json Indicates JSON response format
X-TIMESTAMP	M	String	ISO 8601 datetime format with timezone offset Format: yyyy-MM-ddTHH:mm:ss±HH:mm Example: 2020-12-17T10:55:00+07:00

Body Parameters

Field	Required	Type	Description
code	M	String	API response status code indicating operation result Format: Two-digit string Success: "00", Error: Other codes Used for programmatic response handling
message	M	String	Human-readable response status description Format: UTF-8 encoded string Provides detailed information about the operation result Localized based on request language
orderNo	M	String	Original merchant transaction identifier for reference Format: Same as request orderNo Used for transaction tracking and reconciliation
tradeNo	O	String	Internal transaction reference number for system tracking Format: System-generated alphanumeric string Used for internal transaction management and support
merchant	M	Object	Merchant information container with account details Contains merchant identification and account information See Merchant Model
merchantId	M	String	Primary merchant identifier assigned by the platform Format: Alphanumeric string Used for transaction routing and settlement processing
merchantName	O	String	Registered business name of the merchant Format: UTF-8 encoded string Displayed in payment interface and transaction records
subMerchantId	O	String	Sub-merchant identifier for multi-level merchant structures Format: Alphanumeric string Required for sub-merchant transaction processing
subMerchantName	O	String	Sub-merchant business name for display purposes Format: UTF-8 encoded string Shown in payment interface and transaction records
money	M	Object	Transaction amount details with currency specification Contains confirmed payment amount and currency See Money Model
currency	M	String	ISO 4217 currency code specification Fixed value: THB (Thai Baht) Determines payment processing rules and settlement currency
amount	M	Number	Transaction amount in smallest currency unit Format: Integer value Example: 200 represents THB 200.00 Range: 100-999999999
payAmount	O	Number	Actual payment amount after fees and adjustments Format: Decimal value Example: 199.98 represents THB 199.98 Used for settlement calculations
transactionTime	M	String	ISO 8601 datetime format (yyyy-MM-ddTHH:mm:ss±HH:mm) Example: 2020-12-17T10:55:00+07:00 Timestamp when transaction was processed by the system
channel	M	Object	Payment processing channel details and instructions Contains payment method, URLs, and additional data See Channel Model
status	O	String	Current transaction processing status Format: Predefined status codes Examples: PROCESSING, SUCCESS, FAILED See Status Model

Content-type: application/json
X-TIMESTAMP: 2020-12-17T10:55:00+07:00

{
    "channel": {
        "additionalInfo": {},
        "paymentMethod": "QRPAY",
        "paymentUrl": "https://gateway.smilepayz.com/cashier/#/loading?tradeNo=111200572411191251468673",
        "qrString": "00020101021229370016A0000006770101110113006680870163353037645406299.985802TH63048436"
    },
    "merchant": {
        "accountNo": "11120001202406101410",
        "merchantId": "20001",
        "merchantName": "test"
    },
    "money": {
        "amount": 300,
        "payAmount": 299.98,
        "currency": "THB"
    },
    "orderNo": "878d95fe75ef4c49b11d266afa8dd849",
    "status": "PROCESSING",
    "tradeNo": "111200012411191251468673",
    "transactionTime": "2024-11-19T12:51:47+07:00"
}

{
    "channel": {
        "additionalInfo": {},
        "paymentMethod": "BANK",
      "paymentUrl": "https://gateway.smilepayz.com/cashier/#/loading?tradeNo=1112001125042408363186433",
      "receiverBankName": "KBANK",
      "vaNumber": "2053617290"
    },
    "code": "00",
    "merchant": {
        "accountNo": "11120011202402290943",
        "merchantId": "20011",
        "merchantName": "bradytest123www"
    },
    "message": "Successful",
    "money": {
        "amount": 100,
        "payAmount": 99.99,
        "currency": "THB"
    },
    "orderNo": "20011b5baff0ed8ac4f0c873920e",
    "status": "PROCESSING",
    "tradeNo": "1112001125042408363186433",
    "transactionTime": "2025-04-24T08:36:32+07:00"
}

Notification

HTTP Request

Field	Required	Type	Description
Content-Type	M	String	HTTP notification content type specification Fixed value: application/json Indicates JSON payload format
X-TIMESTAMP	M	String	ISO 8601 datetime format with timezone offset Format: yyyy-MM-ddTHH:mm:ss±HH:mm Example: 2020-12-17T10:55:00+07:00
X-SIGNATURE	M	String	Digital signature for notification verification Format: Base64 encoded signature Used to verify notification authenticity See how to check this value

Body Parameters

Field	Required	Type	Description
orderNo	M	String	Original merchant transaction identifier for reference Format: Same as request orderNo Used for transaction reconciliation and tracking
tradeNo	M	String	Internal transaction reference number for system tracking Format: System-generated alphanumeric string Used for internal transaction management and support
merchantId	M	String	Primary merchant identifier for transaction routing Format: Alphanumeric string Used for merchant identification and settlement processing
merchantName	M	String	Registered merchant business name for display Format: UTF-8 encoded string Shown in transaction records and reports
subMerchantId	O	String	Sub-merchant identifier for multi-level structures Format: Alphanumeric string Included when sub-merchant is involved in transaction
subMerchantName	O	String	Sub-merchant business name for display purposes Format: UTF-8 encoded string Included when sub-merchant is involved in transaction
paymentMethod	M	String	Payment method used for transaction processing Format: Predefined payment method codes Examples: QRPAY, BANK Indicates the actual payment channel used
transactionTime	M	String	ISO 8601 datetime format (yyyy-MM-ddTHH:mm:ss±HH:mm) Timestamp when transaction was completed by payment provider
status	M	String	Final transaction processing status Format: Predefined status codes Examples: SUCCESS, FAILED Indicates the final outcome of the transaction See Status Model
money	M	Object	Final transaction amount details with currency Contains confirmed payment amount and currency May differ from request amount due to fees or adjustments See Money Model
currency	M	String	ISO 4217 currency code specification Fixed value: THB (Thai Baht) Determines payment processing rules and settlement currency
amount	M	Number	Transaction amount in smallest currency unit Format: Integer value Example: 200 represents THB 200.00 Range: 100-999999999
payAmount	O	Number	Actual payment amount after fees and adjustments Format: Decimal value Example: 199.98 represents THB 199.98 Used for settlement calculations
payer	M	Object	Customer information provided during payment Format: Customer data object Contains payer details when available See Payer Model

Return

Important

Notification please return only string SUCCESS

{
  "merchantId": "20001",
  "merchantName": "test",
  "money": {
    "amount": 150,
    "currency": "THB"
  },
  "orderNo": "20001f7d65167e8b1419896f2dfb",
  "payer": {
    "name": "payerName",
    "accountNo": "*****25432"
  },
  "paymentMethod": "QRPAY",
  "status": "SUCCESS",
  "tradeNo": "111200012412151710505955",
  "transactionTime": "2024-12-15T17:10:51"
}

SUCCESS
